BATTERY MODULE 3K PACK
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Module
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
3.0 kWh
80%
50.4 V
Cell: UL1642
ref. UN38.3 and CE design
40 A
-10° to 45°C / 14°F to 113°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Floor Install in an indoor and/or covered outdoor area, or inside a power bank casing.
27 kg / 59.4 lbs
(H x W x D)
550mm x 390mm x 110mm 21.7” x 15.4“ x 14.3”
BATTERY MODULE 4K PACK
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Pack
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
3.84 kWh
80%
51.2 VDC
Cell: UL1642
Refer to UN38.3, UL1973,and IEC62619 design
50 A
-10° to 45°C / 14°F to 113°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Floor Install in an indoor and/or covered outdoor area, or inside a power bank casing.
60 kg / 123.5 lbs
(H x W x D)
436mm x 678mm x 205mm 17.2” x 26.7“ x 8.1”
BATTERY MODULE EOS 5K
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Pack
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
5 kWh
90%
51.2 V
Cell: UL1642
Refer to UN38.3, UL1973 and IEC62619
100 A
-10° to 50°C / 14°F to 122°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Indoors
60 kg
(H x W x D)
595mm x 438mm x 165mm
10-year standard warranty
BATTERY MODULE 6K PACK HV
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Pack
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
6 kWh
90%
156 V
Cell: UL1642
Refer to UN38.3, UL1973 and IEC62619
25 A
-10° to 45°C / 14°F to 113°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Indoors/Outdoors
80 kg / 176 lbs
(H x W x D)
905mm x 654mm x 227mm 35.4” x 25.7“ x 9.0”
10-year standard warranty
BATTERY MODULE 10K PACK HV
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Pack
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
10 kWh
90%
273 V
Cell: UL1642
Refer to UN38.3, UL1973 and IEC62619
25A/40A
-10° to 45°C / 14°F to 113°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Indoors/Outdoors
137 kg / 227 lbs
(H x W x D)
905mm x 654mm x 227mm 35.4” x 23.6“ x 7.9”
10-year standard warranty
BATTERY MODULE 15K PACK HV
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Pack
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
15 kWh
90%
390 V
Cell: UL1642
Refer to UN38.3, UL1973,and IEC62619 design
25A/40A
-10° to 45°C / 14°F to 113°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Indoors/Outdoors
178 kg / 326.3 lbs
(H x W x D)
1205mm x 654mm x 227mm 47.2” x 23.6“ x 7.9”
10-year standard warranty
BATTERY MODULE 20K
TECHNICAL SPECS
POWER
Battery Type
Capacity
Depth of discharge
Voltage
Certification
Max Charge/Discharge
Operating Temp
Storage Temp
Humidity Conditions
Lithium lon Battery
20 kWh
90%
204.8 V
Cell:UL1642
Module:UN38.3.UL1973.IEC62619
25A/50A
-10° to 50°C / 14°F to 122°F
-30° to 60°C / -22°F to 140°F
5% to 95%
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Indoors
200 kgh
(H x W x D)
1289mm x 625mm x 252mm
10-year standard warranty
POWER BANK S4
TECHNICAL SPECS
POWER
AC Power
AC Voltage
PV MPPT Voltage
Battery Type
Capacity
Battery Voltage
Max Charge/Discharge
DOD
Battery Modules
HDMI Interface
Operating Temperature
Certification
Pack
System
3600W
230 VAC 50/60 Hz
125-425 VDC
Lithium lon Battery
3.84 kWh
51.2 VDC
50 A
80%
1
7" LCD
-10° to 45°C / 14°F to 113°F
Cell: UL1642
Refer to UN38.3, UL1973,and IEC62619 design
UL9540, IEC/EN 62109
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Floor Install in indoor and/or covered outdoor area, or inside a power bank casing.
138 kg / 303.6 lbs
(H x W x D)
1230mm x 700mm x 340mm 48.4” x 27.6“ x 13.4”
5-year standard warranty
Optional 5-year extension
BATTERIEMODUL 1
TECHNISCHE DATEN
LEISTUNG
Wechselstrom
Wechselstrom Spannung
PV MPPT-Spannung
Batterietyp
Kapazität
Batteriespannung
Max Charge/Discharge
DOD
Batteriemodule
Batterie ModHDMI-Schnittstellen
Betriebstemperatur
Zertifizierung
Modul
4600 W / 6000 W
230VAC 50/60Hz / 120VAC & 240VAC
120-450 VDC
LFP
7.68 kWh
51.2 VDC
120 A
90%
2
7" LCD
-10° to 45°C / 14°F to 113°F
Cell: UL1642
Refer to UN38.3, UL1973,and IEC62619 design
UL9540, EN 62477-1
SONSTIGE MERKMALE
Montage
Gewicht
Maße
Im zugehörigen Gehäuse
240 kg / 528 lbs
(H x W x D)
1330mm x 750mm x 565mm52.4” x 29.5“ x 22.2”
POWER BANK S12
TECHNICAL SPECS
POWER
AC Power
AC Voltage
PV MPPT Voltage
Battery Type
Capacity
Battery Voltage
Max Charge/Discharge
DOD
Battery Modules
HDMI Interface
Operating Temperature
Certification
Pack
System
5000W / 6000W / 8000W
230VAC 50/60Hz / 120VAC & 240VAC
125-425 VDC
Lithium lon Battery
11.5 kWh
51.2 VDC
100 A
80%
3
7" LCD
-10° to 45°C / 14°F to 113°F
Cell: UL1642
Refer to UN38.3, UL1973,and IEC62619 design
UL9540, IEC/EN 62109
MISCELLANEOUS
Installation
Weight
Dimensions
Warranty
Floor Install in indoor and/or covered outdoor area.
300 kg / 660 lbs
(H x W x D)
1330mm x 750mm x 565mm 52.4” x 29.5“ x 22.2”
5-year standard warranty
Optional 5-year extension
POWER CELL
TECHNICAL SPECS
POWER
AC Power
AC Voltage
PV MPPT Voltage
Battery Type
Capacity
Battery Voltage
Max Charge/Discharge
DOD
Battery Modules
HDMI Interface
Operating Temperature
Certification
Module
30 kW / 50 kW / 100 kW
400VAC / 415VAC / 480VAC
520-800 VDC
Lithium lon Battery
50 kWh / 100 kWh / 150 kWh
250-850 VDC
100 A
80%
7 - 21
LCD
-10° to 50°C / 14°F to 122°F
Cell: UL1642
Refer to UN38.3, UL1973 and IEC62619
Inverter: UL1741, UL9540, CE LVD, CE EMC, IEC 61000
